Migrating from Ecole¶

Gyozas is a pure-Python replacement for Ecole. The APIs are intentionally similar, so migrating is straightforward.

Why switch?¶

	Ecole	Gyozas
Installation	Requires C++ compilation, CMake, custom SCIP build	`pip install gyozas` (only needs `libscip-dev`)
Language	C++ core with Python bindings	Pure Python
Maintenance	Unmaintained since 2023	Actively maintained
Python support	Up to 3.10	3.10+
Dependencies	Custom `ecole` C++ library	PySCIPOpt (pip-installable)
Extensibility	Subclass C++ base classes	Any object with `reset()`/`extract()` (duck typing via Protocol)

API Mapping¶

Environment¶

# Ecole
import ecole
env = ecole.environment.Branching(
    observation_function=ecole.observation.NodeBipartite(),
    reward_function=-ecole.reward.NNodes(),
    information_function=ecole.information.Nothing(),
    scip_params={"separating/maxrounds": 0},
)
instance = next(ecole.instance.SetCoverGenerator())
obs, action_set, reward, done, info = env.reset(instance)

# Gyozas
import gyozas
instances = gyozas.SetCoverGenerator()
env = gyozas.Environment(
    instance_generator=instances,  # pass the generator, not individual instances
    observation_function=gyozas.NodeBipartite(),
    reward_function=-gyozas.NNodes(),   # arithmetic works directly
    dynamics=gyozas.BranchingDynamics(),  # explicit dynamics parameter
    scip_params={"separating/maxrounds": 0},
)
obs, action_set, reward, done, info = env.reset()

Key difference: In Ecole, you pass a single instance to reset(). In gyozas, you pass the generator to the constructor and reset() automatically draws the next instance.

Episode Loop¶

# Ecole
obs, action_set, reward, done, info = env.reset(instance)
while not done:
    action = action_set[0]
    obs, action_set, reward, done, info = env.step(action)

# Gyozas -- identical!
obs, action_set, reward, done, info = env.reset()
while not done:
    action = action_set[0]
    obs, action_set, reward, done, info = env.step(action)

The 5-tuple return signature is the same: (observation, action_set, reward, done, info).

action_set type

In Ecole action_set is a list. In gyozas it is a numpy.ndarray.

Dynamics¶

Ecole	Gyozas	Notes
`ecole.environment.Branching`	`gyozas.BranchingDynamics()`	Pass as `dynamics=` parameter
`ecole.environment.Configuring`	`gyozas.ConfiguringDynamics()`	Single-step parameter tuning
`ecole.environment.PrimalSearch`	`gyozas.PrimalSearchDynamics()`	LP-probing heuristic search
--	`gyozas.NodeSelectionDynamics()`	New in gyozas

Observation Functions¶

Ecole	Gyozas	Notes
`ecole.observation.NodeBipartite()`	`gyozas.NodeBipartite()`	Pure-Python; returns `BipartiteGraph` dataclass
--	`gyozas.NodeBipartiteSCIP()`	Uses PySCIPOpt's C implementation
`ecole.observation.StrongBranchingScores()`	`gyozas.StrongBranchingScores()`	Supports LP and pseudo candidates, configurable `itlim`
`ecole.observation.Pseudocosts()`	`gyozas.Pseudocosts()`	Tracks history across branching nodes
`ecole.observation.Khalil2016()`	--	Not yet implemented
`ecole.observation.Nothing()`	Pass `observation_function=None`
--	`gyozas.MetaObservation([...])`	Combine multiple observations

BipartiteGraph return type

Ecole's NodeBipartite returns a named tuple. Gyozas returns a BipartiteGraph dataclass:

# Ecole
col_feat, (edge_idx, edge_val), row_feat = obs

# Gyozas
col_feat  = obs.variable_features
row_feat  = obs.row_features
edge_idx  = obs.edge_features.indices
edge_val  = obs.edge_features.values

Reward Functions¶

Ecole	Gyozas	Notes
`ecole.reward.NNodes()`	`gyozas.NNodes()`
`ecole.reward.LpIterations()`	`gyozas.LPIterations()`
`ecole.reward.SolvingTime()`	`gyozas.SolvingTime()`
`ecole.reward.IsDone()`	`gyozas.Done()`
`ecole.reward.PrimalIntegral()`	`gyozas.PrimalIntegral()`
`ecole.reward.DualIntegral()`	`gyozas.DualIntegral()`
`ecole.reward.PrimalDualIntegral()`	`gyozas.PrimalDualIntegral()`
`-1.5 * reward ** 2` (arithmetic)	`-1.5 * gyozas.NNodes() ** 2`	Fully supported via `ArithmeticMixin`

Information Functions¶

Ecole	Gyozas	Notes
`ecole.information.Nothing()`	`gyozas.Empty()`	Default
--	`gyozas.informations.TimeSinceLastStep()`	Wall-clock delta per step

Instance Generators¶

Ecole	Gyozas	Notes
`ecole.instance.SetCoverGenerator()`	`gyozas.SetCoverGenerator()`
`ecole.instance.IndependentSetGenerator()`	`gyozas.IndependentSetGenerator()`
`ecole.instance.CombinatorialAuctionGenerator()`	`gyozas.CombinatorialAuctionGenerator()`
`ecole.instance.CapacitatedFacilityLocationGenerator()`	`gyozas.CapacitatedFacilityLocationGenerator()`
`ecole.instance.FileGenerator(...)`	`gyozas.FileGenerator(...)`

Seeding works the same way:

# Ecole
generator = ecole.instance.SetCoverGenerator()
generator.seed(42)

# Gyozas -- same, or pass rng= to constructor
generator = gyozas.SetCoverGenerator(rng=42)
# or
generator.seed(42)

Custom Components¶

In Ecole, custom functions require subclassing C++ base classes. In gyozas, any object with the right methods works (structural subtyping via Protocol):

# Ecole -- must inherit from ecole.reward.RewardFunction (C++ class)
class MyReward(ecole.reward.RewardFunction):
    def before_reset(self, model):
        ...
    def extract(self, model, done):
        ...

# Gyozas -- just implement the methods, no inheritance needed
class MyReward:
    def reset(self, model):
        ...
    def extract(self, model, done):
        ...

Method naming

Ecole uses before_reset() while gyozas uses reset().

Full Migration Example¶

# --- Ecole ---
import ecole

generator = ecole.instance.SetCoverGenerator(n_rows=100, n_cols=200)
env = ecole.environment.Branching(
    observation_function=ecole.observation.NodeBipartite(),
    reward_function=ecole.reward.LpIterations(),
    scip_params={"separating/maxrounds": 0, "presolving/maxrounds": 0},
)

for _ in range(10):
    instance = next(generator)
    obs, action_set, reward, done, info = env.reset(instance)
    while not done:
        action = action_set[0]
        obs, action_set, reward, done, info = env.step(action)

# --- Gyozas ---
import gyozas

instances = gyozas.SetCoverGenerator(n_rows=100, n_cols=200)
env = gyozas.Environment(
    instance_generator=instances,
    observation_function=gyozas.NodeBipartite(),
    reward_function=gyozas.LPIterations(),
    scip_params={"separating/maxrounds": 0, "presolving/maxrounds": 0},
)

for _ in range(10):
    obs, action_set, reward, done, info = env.reset()
    while not done:
        action = action_set[0]
        obs, action_set, reward, done, info = env.step(action)

env.close()  # gyozas requires explicit cleanup

What's Not Yet Ported¶

These Ecole features are not yet available in gyozas:

Khalil2016, Hutter2011, MilpBipartite observation functions

Contributions are welcome! See CONTRIBUTING.md.
